Dimensions

• Width : 2.38 - 2.42 Meters
• Length : (Short Box Model) 5.82 Meters
• Length : (Long Box Model) 6.60 - 6.65 Meters
• Total Height (Roof A/C are included): 3.10 Meters

Standard Option

• Microwave: Odyssey
• Fridge: Dometic NRX115C
• Water System: Pentair Revolution Pump, Waste Tank 80L; Fresh Tank 120L and City Water
• Electrical Step: ORANT YS550-E Single Step
• Inlet Socket: FAWO
• Breaker / Fuse: ALKO Nordeletronica Italy
• Table Leg: Fiamma Table Leg Set
• Induction Stove: Odyssey
• Toilet: Freucamp Cassette Toilet W5000
• Rooftop Aircon: myCoolman CCA3000 : 10200 BTU/h
• Power System OASIS POWER II: Inverter 5kW / Battery 9kWh
• DC to DC Converter OASIS POWER: 600W
• Water Heater: OASIS
• Awning: Odyssey Manual
• Wheel: Orginal Wheel
• Suspension: Orginal Suspension
• Steady Leg: ALKO Manual 2 legs

• Lithium Iron Phosphate (LiFePO4) Battery with 5kW Capacity
• AC output power up to 5,000VA / 5kW (Expandable up to 45kW)
• Supports battery connection from 51.2V / 280Ah / 14.3kWh (Battery1) up to 200kWh (Battery14) for extended power supply duration
• Cycle Life: 3,000+ cycles

• Rechargeable from household power 220–240VAC and generator 230VAC

• Rechargeable via MPPT solar system, compatible with solar panels of 65VDC or higher

• Rechargeable from vehicle alternator: supports charging input to Oasis Power II at 600W (Standard DC to DC Converter: 600W)

• Maximum input power control: 5kW

• LCD display shows battery capacity, charging status, AC/DC status, and other operational indicators

• Adjustable input power control via LCD screen: 600–3,000W (for limited power sources)

• Equipped with protection systems for Overload / Over Temperature / Short Circuit

• Auto-restart function when AC power recovers

• Smart battery charger design for optimized battery performance

• Cold Start Function
